1900rpm Rated Speed 4 X 2 Water Bowser Truck With 250KW Power ZF Tech Transmission

Name: 1900rpm Rated Speed 4 X 2 Water Bowser Truck With 250KW Power ZF Tech Transmission
Brand: SINOWAY
Price: 1 USD

Brand Name : SINOWAY

Model Number : SWWT2000

Certification : ISO9001

Place of Origin : China

MOQ : 1 unit

Price : Negotiation

Payment Terms : L/C, D/A, D/P, T/T, Western Union

Supply Ability : 50 units per month

Delivery Time : 30 days

Packaging Details : Nude

Product name : Water Truck

Engine : SINOWAY SW6D18.340

Rated power : 250kw

Max. torque : 1566N.m/1250rpm

Tank capacity : 20000L

Tyre : 11.00R20

Contact Now

4x2 Water Truck with 250KW Power 20000LTank Capacity ZF Tech Transmission

Engine
Model	SINOWAY SW6D18.340
Type	Mechanical,6 cylinder, water-cooled, turbocharged, direct-injection
Rated power	250kw
Rated speed	1900rpm
Max. torque	1566N.m/1250rpm
Main Technical Specification
N.V.W	12000kg
Pay-loading capacity	21000kg
G.V.W	33000kg
Axle loading capacity (F/R)	7000/2x13000kg
Max. travelling speed	90km/h
Grade ability	30%
Ground clearance	285mm
Fuel tank capacity	320L (Aluminium)
Water Tank
Tank capacity	20000L
Dimensions
Overall size (L x W x H)	11200 x 2500 x 3450mm
Wheel base	4650 + 1350mm
Tread (F/R)	2065/1860/1860mm
Transmission System
ZF tech. transmission, mechanical with synchronizer
Ratio
Forward	13.22, 10.54, 7.37, 5.21, 3.47, 2.16, 1.54, 1.00
Reverse	14.26
Frame
Type	Parallel, tapered channel section type with reinforcements, stiffeners and cross members
Size (H x W)	316 x 90 (8+6) mm
Width (front/rear)	940/850mm
Steering System
Hydraulic steering with power assistance (HITACHI)
Driving position	Left hand drive
Axle And Tire
Front axle	Stub axle with double T-cross section
Rear axle	Double reduction with hub reduction and final drive ratio: 5.73
Tyre	11.00R20
Clutch And Brake
Single-plate dry coil-spring clutch, hydraulically operated with air assistance
Service brake	Dual circuit compressed air brake
Parking brake	Spring energy operating on rear wheels
Auxiliary brake	Exhaust brake
Electric System
Batteries	2 x 12Volt - 150Ah x 2
Alternator	24 Volt / 70A
Starter	24 Volt / 7.80kw
Suspension
Front suspension	9 semi-elliptic leaf spring
Rear suspension	12 semi-elliptic leaf spring
Cab
SINOWAY style cab, four point suspension, tilting air bag, floating cab by manual control mechanism, normal roof with air conditioner and laminated glass, power window.

Product Tags:

huge dump truck

heavy dump truck

Wholesale 1900rpm Rated Speed 4 X 2 Water Bowser Truck With 250KW Power ZF Tech Transmission from china suppliers

1900rpm Rated Speed 4 X 2 Water Bowser Truck With 250KW Power ZF Tech Transmission Images
